Creating the radar alarm zone (Make Sector Alarm)
Procedures 1 Press the [AZ] key for 2 seconds.
The AZ Menu will appear.
2 Open the Make Sector Alarm menu by performing the following menu
operation.
4. RADAR Alarm
→ 3. Make Sector Alarm
3 Press the [1] key or [2] key.
The range setting for Sector Alarm1 or Sector Alarm2 starts.
4 Turn the [EBL] dial and the [VRM] dial to set the start bearing and the
start range, and then press the [ENT] key.
5 Turn the [EBL] dial and the [VRM] dial to set the end bearing and the
end range, and then press the [ENT] key.
The radar alarm zone is determined.
Setting the [AZ] key allocation (Set AZ Key)
Only by pressing the [AZ] key, the normally-used radar alarm can be easily turned on
/ off.
Procedures 1 Press the [AZ] key for 2 seconds.
The AZ Menu will appear.
2 Open the Sector RADAR Alarm menu by the following menu
operation.
5. Set AZ Key
→ 2. Sector RADAR Alarm
3 Set the [AZ] key allocation.
On : Pressing the [AZ] key will turn on or off the radar alarm.
Off : Even if the [AZ] key is pressed, the radar alarm zone is not turned on.
Note: When the automatic acquisition / activation zone key allocation is set, pressing the [AZ] key
will simultaneously turn on or off the radar alarm in the automatic acquisition / activation
zone.
3-49
