[III] Saving navigation data (Save User Map)
Navigation data can be saved when navigation equipment is connected, or the own
ship position on the user map is entered in the manual mode.
Procedures 1 Insert a flash memory card into the card slot.
Flash memory card (option) is necessary.
For the insertion and removal of the card, see HOW TO INSERT AND REMOVE A
CARD in the appendix.
2 Open the File Operations menu by performing the following menu
operation.
Plot
→ 1. Mark Setting
→ 3. File Operations
3 Press the [1] key to select a card slot.
Slot1 and Slot2 of the Select Card Slot items are switched.
4 Press the [5] key.
The Input File Name menu will appear.
5 Enter the file name to be saved.
Up to 10 characters can be entered.
For the input method on the character input screen, see Section 3.3.4.
After the data has been entered, Confirmation Window will appear.
6 Press the [1] key.
Navigation data currently being displayed is saved.
3-75
