[II] Transmission Monitor Adjustment (MON Indicator Adjustment)
Adjust the circuit for monitoring the transmission performance of the radar equipment.
Note: The radar system is equipped with an interswitch.
For adjusting the performance unit, set the interswitch connection to straight, i.e. No.1
scanner is connected to No.1 display unit as the Master.
Procedures 1. Open the Serviceman Menu.
2. Open the MON (Performance Monitor) Indicator Adjustment menu by
performing the following menu operation.
1. Adjust Menu
→ 4. TXRX Adjustment
→ 5. MON Indicator Adjustment
3. Increase or decrease the adjustment value so that the performance
monitor level indicator will be adjusted to "8."
Adjusted to 8
4. Press the Exit button to close the adjustment menu.
Note: During performance monitor adjustment, all acquisitions by the target tracking function are
released.
The released target acquisitions are not recovered.
7-37
To Next Page
