9.2 Trouble Shooting

yyyy

Caution: Use the specified magnetron in table 9-11.

Table 9-11 Special Parts

[I] JMA-5312-6/6HS

Parts No. Name Type Manufacturer Location Code

V101 Magnetron MAF1565N NJRC Scanner unit 5VMAA00102

A101/A102 Circulator FCX68R

Orient

Microwave

Scanner unit 5AJIX00027

A103 Dummy NJC4002 NJRC Scanner unit 5ANDF00001

A104 Filter NJC9952 NJRC Scanner unit 5AWAX00002

A301 Diode Limiter NJS6930 NJRC Scanner unit 5ATBT00006

[II] JMA-5322-7/9/6HS

Parts No. Name Type Manufacturer Location Code

V101 Magnetron M1568BS NJRC Scanner unit 5VMAA00106

A101/A102 Circulator NJC3901M NJRC Scanner unit 5AJBV00007

A103 Dummy NJC4002 NJRC Scanner unit 5ANDF00001

A104 Filter NJC9952 NJRC Scanner unit 5AWAX00002

A301 Diode Limiter NJS6930 NJRC Scanner unit 5ATBT00006

[III] JMA-5332-12

Parts No. Name Type Manufacturer Location Code

V101 Magnetron M1555 NJRC Scanner unit 5VMAA00104

A101 Circulator NJC3316 NJRC Scanner unit 5AJBV00008

A301 Diode Limiter NJS6318 NJRC Scanner unit 5ATBT00005

9-8
