4 Electrical connection
23
Potentiometer/WFG
A: Start resistance
S: Loop resistance
E: End resistance
Thermocouple
Double thermocouple
(galvanically isolated)
mV input (0 to 1 V)
4to20mA
0to20mA
0to10V
Terminals Comment Screw terminals
51,52,53,54
41,42,43,44
