7 Configuration
66
W3Re-W25Re "D" ASTM E1751M-09 (up to 2315 °C): 2009 -0 to +2315 °C
Platinel type PLII -0 to +1395 °C
Customer-specific This setting only appears if a customer-specific linearization has been entered via the setup
program and transferred to the device.
v Chapter 10.4 "Kundenspezifische Linearisierung"
Parameter Comment
Value range
(default setting in bold)
7.4.3 Temperature difference
This setting is only available if "thermocouple" has
been configured under linearization.
0to10 to 100
7.4.4 Temperature compens.
Internal, fixed value
7.4.5 Resistance measuring
range
The measuring range can be selected here if "linear" or
"customer-specific" has been set for linearization and
"resistance/potentiometer" or "RTD temperature
probe" has been set as the sensor type.
400, 4,000, 10,000 Ω
7.4.6 Line resistance
Resistance of probe line (for 2-wire circuit) 0.0 to 100 Ω
7.4.7 Sensor factor
Only for RTD temperature probe:
For adjusting Pt25 to Pt1000 sensors to a different set
linearization (e.g. Pt100).
For example, a Pt100 linearization can be corrected
with the sensor factor 0.5 in order to connect a Pt50
sensor.
0.25 to 1.00 to 10.00
7.4.2 Linearization
Comment Measuring range
