9 Technical data
86
9.3 Test voltages
9.4 Electrical safety
9.5 Analog output
Current
4 to 20 mA
0 to 20 mA
is detected
is detected
is detected
is not detected
is detected
is not detected
Input and output against voltage supply
- With voltage supply AC 110 to 240 V +10%, -15% 4260 V
- With voltage supply DC 24 V 4260 V
Clearances / creepage distances
Mains voltage to electronic com-
ponents and probes
≥ 8mm
/ ≥ 4mm
Mains voltage to relays ≥ 8mm
/ ≥ 4mm
Relays to electronic components
and probes
≥ 8mm
/ ≥ 4mm
Resolution D/A converter >15 bit Load resistance R
load
Accuracy Burden influence
Voltage DC 0(2) to 10 V
Current DC 0(4) to 20 mA
≥ 500 Ω
≤ 500 Ω
≤ ±0.05% referring to 10 V
≤ ±0.05% referring to 20 mA
≤ ±15 mV
≤ ±0.02 %/100 Ω
Measuring probe Out of range Probe/cable break Probe/cable short circuit
