JUMO dTRANS T06 - Analog Input (Part of the Safety Channel)

4 Electrical connection
22
Terminals Comment Screw terminals
4.2.1 Analog input (part of the safety channel)
k Default setting
RTD temperature probe
in two-wire circuit
RTD temperature probe
in three-wire circuit
RTD temperature probe
in four-wire circuit
Resistance/potentiometer
in two-wire circuit
Resistance/potentiometer
in three-wire circuit
Resistance/potentiometer
in four-wire circuit
51,52,53,54
41,42,43,44
