08.11 EN
162
Draining the engine oil
Procedure
• Remove the floorboard.
• Unscrew the filler cap (164).
• Thoroughly clean the oil drain plug
(165) and around the drain hole.
• Unscrew the oil drain plug.
• Collect any oil that emerges.
• Screw in the oil drain plug with a new
seal.
Replace the engine oil filter
Procedure
• Undo the hose clamp (167) from the
hose (168).
• Pull off the hose.
• Loosen the quick release on the
strap retainer of the air filter and set
the air filter housing (166) to the side.
• Undo the oil filter (171) with a filter
wrench and manually unscrew it.
Z Collect any emerging oil and dispose
of the oil and oil filter in accordance
with environmental regulations.
• Thoroughly clean the raised faces of the oil filter flange.
• Apply a thin layer of fresh engine oil to the seal of the new oil filter.
• Hand-tighten the oil filter.
• Fit the air filter, insert the hoses and tighten with hose clamps.
165
164
167
166
168
