167
08.11 EN
Draining the engine oil
Procedure
• Remove the floorboard.
• Unscrew the filler cap (164).
• Thoroughly clean the oil drain plug (165) and
around the drain hole.
• Unscrew the oil drain plug.
• Collect any oil that emerges.
• Screw in the oil drain plug with a new seal.
Replace the engine oil filter
Procedure
• Undo the oil filter (161) with a filter wrench
and manually unscrew it.
• Thoroughly clean the sealing faces of the oil
filter flange.
• Apply a thin layer of engine oil to the seal of
the new oil filter.
• Hand-tighten the oil filter.
Adding engine oil
Procedure
• Add fresh engine oil through the filler port
(164) in accordance with the consumables
table.
• Check the engine oil level with the dipstick
(163) and top up if necessary, (see
"Consumables" on page 151).
• Screw the filler cap back on.
• Attach the floor plate.
165
164
176
163
164
