08.11 EN
20
1)
for vertical mast.
2)
The values shown represent the maximum gradeability to overcome short
differences in height and surface unevenness (surface edges). The truck must not
operate on inclines of more than 15%.
TFG 316/320
Description TFG 316 TFG 320
Q
C ap ac i ty
where C = 500 mm)
1)
1600 2000 kg
C Load centre distance 500 500 mm
Travel speed* with /
without load
18.7/19.5 18.5/19.3 km/h
Lift speed, with / without
load
0.61/0.63 0.60/0.63 m/s
Lowering speed with /
without load
0.55/0.49 0.57/0.49 m/s
Gradeability
2)
*
with / without load
25 22 %
Acceleration* with /
without load to 15 m
5.1/4.7 5.2/4.5 s
Available working
pressure for attachments
160 160 bar
Oil flow for attachments 45 45 l/min
