Figure 45: Install the ACX5448 Router in a Four-Post Rack
g100130
Figure 46: Install the ACX5448-D Router in a Four-Post Rack
g100532
Figure 47: Install the ACX5448-M Router in a Four-Post Rack
g100709
7. Install mounting screws into each of the front-mounting bracket holes aligned with the rack, starting
from the bottom, and secure them tightly. Figure 48 on page 92, Figure 49 on page 92, and
Figure 50 on page 92 show the router fully secured to the front rails of the four-post rack.
