Juniper MX204 - Locating the Chassis Serial Number ID Label on an MX204; Locating the Serial Number ID Labels on MX204 Power Supplies

Xcvr 0 REV 01 740-058732 F5I2018309 QSFP-100GBASE-LR4
Xcvr 1 REV 01 740-054053 QF027546 QSFP+-4X10G-SR
Xcvr 2 REV 01 740-058732 1AMQA14203X QSFP-100GBASE-LR4
Xcvr 3 REV 01 740-058732 1GCQA0370CK QSFP-100GBASE-LR4
PIC 1 BUILTIN BUILTIN 8XSFPP PIC
PEM 0 REV 02 740-070749 1F186390026 AC AFO 650W PSU
PEM 1 REV 04 740-043886 1GA46361256 JPSU-650W-DC-AFO
Fan Tray 0 Fan Tray, Front to Back
Airflow - AFO
Fan Tray 1 Fan Tray, Front to Back
Airflow - AFO
Fan Tray 2 Fan Tray, Front to Back
Airflow - AFO
Locating the Chassis Serial Number ID Label on an MX204
The serial number ID label is located on a label on the top of the chassis. See Figure 55 on page 140 for the
location on an MX204.
Figure 55: MX204 Chassis Serial Number Label
g0 0 9893
Serial number ID label
Locating the Serial Number ID Labels on MX204 Power Supplies
The power supplies installed in an MX204 are field-replaceable units (FRUs). For each FRU, you must
remove the FRU from the router chassis to see the FRU serial number ID label.
•
AC power supply—The serial number ID label is on the top of the AC power supply. See
Figure 56 on page 141.
