Juniper MX204 - Connector Pinouts for an MX Series CB-RE or RCB Management Port

Table 24: RJ-45 Connector Pinout for the AUX and CONSOLE Ports (continued)
DescriptionSignalPin
Data Set ReadyDSR/DCD7
Clear to SendCTS8
RJ-45 Connector Pinouts for an MX Series CB-RE or RCB Management
Port
The port on the Control Board and Routing Engine (CB-RE; Routing and Control Board (RCB)) labeled
MGMT is an autosensing 10/100/1000-Mbps Ethernet RJ-45 receptacle that accepts an Ethernet cable
for connecting the Routing Engine to a management LAN (or other device that supports out-of-band
management).
NOTE: In routers where the Routing Engine and Control Board (CB) are integrated into a single
board, a CB-RE is known as Routing and Control Board (RCB). The RCB is a single FRU that provides
Routing Engine and CB functionality.
Table 25 on page 69 describes the RJ-45 connector pinout.
Table 25: RJ-45 Management Port Connector Pinouts for the CB-RE or RCB MGMT Port
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1–2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3–5
Transmit/receive data pair 2TRP2–6
Transmit/receive data pair 4TRP4+7
69
