Table 4: MX204 Router Hardware Components and CLI Terminology (continued)
DescriptionCLI Name
Hardware Model
NumberComponent
N/AFPCN/A (built-in)MPC
N/ARE-S-2X00x6N/A (built-in)Routing Engine
Hardware Compatibility ToolXcvrSee MX Series Interface
Module Reference.
Transceiver
Table 5 on page 27 lists the spare parts and blank panels available for the router.
Table 5: MX204 Spare Parts and Blank Panels
DescriptionModel Number
MX204 chassis, spareJNP204-CHAS
MX204 power blank cover panelJNP-PWR-BLNK-1
MX204 Front and Rear Panel Components
IN THIS SECTION
Front Panel Components | 27
Rear Panel Components | 28
Front Panel Components
The front panel on the front of the router enables you to view status and troubleshooting information at
a glance. The front panel contains LEDs for the router components, online/offline and reset buttons,
auxiliary and console ports, clocking ports, and interface ports. “MX204 Chassis Description” on page 23
shows the front of the fully configured chassis.
