Juniper MX204 - AC Power Circuit Breaker Requirements for the MX204 Router

Table 11: AC Power System Electrical Specifications
SpecificationItem
Operating range: 100 through 240 VACAC input voltage
50 through 60 Hz (nominal)AC input line frequency
3.2 A @ 100 VAC
1.37 A @ 240 VAC
AC system current rating
312 WAC system input power
Table 12 on page 39 lists the AC power supply electrical specifications.
Table 12: AC Power Supply Electrical Specifications
SpecificationItem
650 WMaximum output power
Operating range:
100 through 127 VAC
200 through 240 VAC
AC input voltage
50 to 60 Hz (nominal)AC input line frequency
7.8 A @ 100 VAC
3.8 A @ 240 VAC
AC input current rating
SEE ALSO
Maintaining the MX204 Power Supplies | 126
AC Power Circuit Breaker Requirements for the MX204 Router
We recommend that you use a dedicated customer-site circuit breaker rated for 20 A (110 VAC) minimum
or 16 A (220 VAC) minimum for each AC power feed, or as required by local code. Doing so enables you
to operate the router in any configuration without upgrading the power infrastructure.
39
