Juniper MX204 - MX204 DC Power System; MX204 Router DC Power Specifications

SEE ALSO
General Safety Guidelines and Warnings | 147
General Electrical Safety Guidelines and Warnings | 172
Prevention of Electrostatic Discharge Damage | 173
MX204 DC Power System
IN THIS SECTION
MX204 Router DC Power Specifications | 42
DC Power Circuit Breaker Requirements for the MX204 Router | 43
DC Power Source Cabling for MX204 Router | 44
DC Power Cable Specifications for MX204 Router | 45
MX204 Router DC Power Specifications
Table 14 on page 42 lists the DC power system electrical specifications.
Table 14: DC Power System Electrical Specifications
SpecificationItem
Operating range: –40 through –72 VDCDC input voltage
20 A @ –44 VDC (maximum)DC system input current
rating
331 W
7.75 A @ –44 VDC
DC system input power
Table 15 on page 43 lists the DC power supply electrical specifications.
42
