Connecting the MX204 to Power
IN THIS SECTION
Tools and Parts Required for MX204 Router Grounding and Power Connections | 89
Grounding the MX204 Router | 90
Connecting Power to an AC-Powered MX204 Router | 91
Powering On an AC-Powered MX204 Router | 94
Connecting Power to a DC-Powered MX204 Router | 95
Powering On a DC-Powered MX204 Router | 98
Powering Off the MX204 Router | 99
Tools and Parts Required for MX204 Router Grounding and Power
Connections
To ground and provide power to the router, you need the following tools and parts:
•
Phillips (+) screwdrivers, numbers 1 and 2
•
Socket nut driver
•
2.5-mm flat-blade (–) screwdriver
•
Torque-controlled driver, with a maximum torque capacity of 6 lb-in. (0.7 Nm), for tightening screws to
terminals on each power supply on a DC-powered router
CAUTION: The maximum torque rating of the terminal screws on the DC power supply
is 6 lb-in. (0.7 Nm). The terminal screws might be damaged if excessive torque is applied.
Use only a torque-controlled driver to tighten screws on the DC power supply terminals.
Use an appropriately sized driver, with a maximum torque capacity of 6 lb-in. or less.
Ensure that the driver is undamaged and properly calibrated and that you have been
trained in its use. You might want to use a driver that is designed to prevent overtorque
when the preset torque level is achieved.
•
Wire cutters
•
Electrostatic discharge (ESD) grounding wrist strap
89
