MULTICAL® 402
Kamstrup A/S · Technical Description · 5512-742_M1_GB_01.2016
27
Figure 4: Flow sensor with G5/4 and G2 threaded connection
Thread L M H2 A B1 B2 H1
Approx.
weight
[
kgs.
]
G5/4 260 L/2 88.7 17 50.5 22 48.5 2.9
G2 300 L/2 88.7 21 50.5 31 48.5 5.1
Table 3: Weight is inclusive of 3 m sensor set, but exclusive of packing
