K&R ACD320 Series User Manual

ACD320 user manual Parameter Description
- 107-
BIT6:RA，RB，RC 64
BIT7:DO-R 128
BIT8:TA，TB，TC 256
Function Code Name Setting Range
Default
Value
F9.01
Carrier wave selection
with the temperature
adjustment
0:Invalid
1: Valid
1
When it is effective that carrier wave adjusts with the temperature, inverter detect the
temperature of IGBT heat sink, the carrier wave frequency will change automatically when
exceeding a certain value. Set it invalid for the noise scene of high requirements.
Function Code Name Setting Range
Default
Value
F9.02 Accelerating time 3 0.1～3600.0 20.0
F9.03 Decelerating time 3 0.1～3600.0 20.0
Only when the constant pressure water supply PID is valid, the absolute value of
inaccuracy between feedback pressure and the set pressure, within PID adjustment range (F7.26),
F9.02 and F9.03 is valid.
Function Code Name Setting Range
Default
Value
F9.09
AO2 analog output
selection
0～10 0
Standard output of analog output is 0 ~ 20mA or 0 ~ 10V, current or voltage output can be
selected by controlling the J5. The range of the corresponding value it indicates is as shown in
the following table:
Setting Function Range
0 Set frequency
0 to maximum
output frequency
1 Running frequency
0 to maximum
output frequency
2 Output current 0 to 200% of the rated current of the
