ACD320 user manual Parameter Description
- 108-
motor
3 Output voltage
0 to 150% of the rated voltage of
the motor
4 Running speed
0 to 200% of the rated running
speedof the motor
5 Output power 0 to 200% rated power of the motor
6 Output torque
0 to 200% of the rated current of the
motor
7
Analog value AVI
input
0～ 10V/0～20mA
8
Analog value ACI
input
0～ 10V/0～20mA
9～10 Reserved Reserved
Function Code Name Setting Range
Default
Value
F9.10
AO2 analog output lower
limit
0.0%～100.0% 0.0%
F9.11
AO2 lower limit
corresponding analog
0.00～10.00V 0.0%
F9.12
AO2 analog output upper
limit
0.0%～100.0% 100.0%
F9.13
AO2 upper limit
corresponding analog
0.00V～10.00V 10.00V
The above function code defines the relationship between the output value and the analog
output corresponding value, the part of the output value that exceeding the maximum or
minimum output setting scope will be calculated according to the maximum or minimum output.
When analog output is the current output, 1mA current is equivalent to the 0.5V voltage.
In different applications, 100% of analog output corresponding to the output values are
different, please refer to the specific description of each application part.
