K&R ACD320 Series User Manual

ACD320 user manual Appendix
- 144-
Appendix 3 Parameter illustration of the inverter specially used for one driving one
constant pressure water supply
1. Parameter illustration of running mode macroinstruction
Function
code
Name Setting range
Macroins
truction
setting
Chang
e
Commu
nication
address
Basic parameters
F0.00 Speed control mode 0～2 1 × 0
F0.01
Running command
channel
0～2 1 × 1
F0.03
Frequency command
selection
0～8 5 ○ 3
F0.05
Running frequency
upper limit
0.00～Maximum frequency
49.00 ○ 5
F0.06
Running frequency
lower limit
0.00～F0.05 20.00 ○ 6
F0.08 Acceleration time 1 0.1～3600.0s 10.0s ○ 8
F0.09 Deceleration time 1 0.1～3600.0s 10.0s ○ 9
F2.01
MI1 function
selection
23:One driving two circularly water supply mode
is ineffective（switch to manual operation）
23 × 52
F3.05
Display selection
of running status
parameter
1～65535 1183 ○ 83
F3.06
Display selection
of stopping status
parameter
1～511 207 ○ 84
F3.07
Display of operating
status selected
preferentially
0～15（0: It is invalid to select preferentially） 0 ○ 85
F4.18
PID setpoint Sources
Option
0：（F4.19）Digital provision 0 × 115
F4.19 Preset PID setpoint 0.0%～100.0% 50.0% ○ 116
F4.20
PID Feedback
Sources Option
0：AVI effective 0 × 117
F4.21
PID Output
Characteristics Option
0～1 0 × 118
F4.22
Proportional gain
(Kp)
0.00～100.00 5.00 ○ 119
F4.23 Integral time (Ti) 0.01～10.00s 0.50s ○ 120
F4.24 Differential time (Td) 0.00～10.00s 0.10s ○ 121
F4.25
Sampling cycletime
(T)
0.01～100.00s 0.10s ○ 122
F4.26
PID control
discrepancy limit
0.0～100.0% 5.0% ○ 123
F4.27
Feedback
disconnection
detecting value
0.0～100.0% 0.0% ○ 124
F4.28
Feedback
disconnection
detecting time
0.0～3600.0s 1.0s ○ 125
F9.02 Acce. time 3 0.0～3600.0s 445.0s ○ 202
F9.03 Dece. time 3 0.0～3600.0s 445.0s ○ 203
F7.26 PID adjusting range 0～50.0 5.0 ○ 175
Parameters when sleeping and revival and lack of water detection are needed
