K&R ACD320 Series - Page 58

ACD320user manual Function parameters list
- 53-
F9.09
AO2 analog output
selection
0: setting frequency
1: running frequency
2: output current
3: output voltage
4: running speed
5: output power
6: output torque
7: analog AVI input value
8: analog ACI input value
9～10: Reserved
0 ○ 209
F9.10
AO2 analog output
lower limit
0.0%～100.0% 0.0% ○ 210
F9.11
AO2 lower limit
corresponding
analog
0.00～10.00V 0.0% ○ 211
F9.12
AO2 analog output
upper limit
0.0%～100.0% 100.0% ○ 212
F9.13
AO2 upper limit
corresponding
analog
0.00V～10.00V 10.00V ○ 213
FA Reserved.
Fb Reserved
FC Reserved
Fd Reserved
FE Default parameters
Note: Please refers to F3.05，F3.06，F3.07 for the selection of upervision parameter, more details refer to Chapter
4 and Chapter 6.
