K&R ACD320 Series User Manual

ACD320user manual Function parameters list
- 52-
the value of F1.19）
3: Analog AVI+ACI setting torque （ 100.0% is
equal to the value of F1.19）
4: Multisection torque setting （100.0% is equal to
the value of F1.19）
5: Telecommunication setting（100.0% is equal to
the value of F1.19），that is the actual torque setting
value = 100.0% * F1.19.
F8.07
Keyboard setting
torque
-100.0% ～ 100.0% ）（ 100.0% is equal to the
value of F1.19）
50．0% ○ 197
F8.08
Upper limit Freq.
setting selection
0: Keyboard set the upper limit Freq. (F0.05)
1:Analog AVI set upper limit
Freq.( 100%corresponds to the max. fre. of
F0.04)
2: Analog ACI set upper limit Freq.(the same as 1)
3: Multisection setting upper limit Freq. (the same
as 1)
4: Telecommunication setting upper limit Freq.
(the same as 1)
0 ○ 198
F8.09
Current limit
selection(selection
of hardware
overcurrent)
0: Current limit is effective all the time(and
hardware overcurrent is ineffective)
1: Current limit is ineffective when run at constant
speed(and hardware overcurrent is effective)
0 ○ 199
F9 Supplementary function Parameters 2
F9.00
Polarity selection
of input and output
terminal
BIT0:MI1 1
0 ○ 200
BIT1:MI2 2
BIT2:MI3 4
BIT3:MI4 8
BIT4:MI5 16
BIT5:MI6 32
BIT6:RA，RB，RC 64
BIT7:DO-R 128
BIT8:TA，TB，TC 256
F9.01
Carrier wave
selection with the
temperature
adjustment
0: Effective
1: Ineffective
1 ○ 201
Function
Code
Name Set range
Default
Value
Modifi
cation
Serial
No
F9.02 Acce. time 3 0.1～3600.0s 445.0 ○ 202
F9.03 Dece. time 3 0.1～3600.0s 445.0 ○ 203
F9.04
F9.08
Reserved.
