K&R ACD320 Series User Manual

ACD320user manual Function parameters list
- 51-
BIT3: Reserved. 8
BIT4: Inverter overload shield.
0:Invalid 1: Valid
16
BIT5: Input lack-phase shield.
0:Invalid 1: Valid
32
BIT6: Output lack-phase shield.
0:Invalid 1: Valid
64
BIT7: Reserved. 128
BIT8: current detecting circuit
failure
0:Invalid 1: Valid
256
BIT9: Earthing short circuit
failure shield.
0:Invalid 1: Valid
512
BIT10: Inverter over heating
shield.
0:Invalid 1: Valid(all frequency
section is valid)
1024
Note:Please refer to F8.09 for hardware
overcurrent shield.
Function
Code
Name Set range
Default
Value
Modifi
cation
Serial
No
F8 Supplementary function Parameters 1
F8.00
Inhibit oscillation
low frequency
threshold point
0～500 5 ○ 190
F8.01
Inhibit oscillation
high frequency
threshold point
0～500 100 ○ 191
F8.02
Inhibit oscillation
scope limit value
0～10000 5000 ○ 192
F8.03
Inhibit oscillation
dividing frequency
of low and high
frequency
0.00～F0.04（max. freq.） 12.50 ○ 193
F8.04 Inhibit oscillation
0: Oscillation inhibit is valid.
1: Oscillation inhibit is invalid.
1 ○ 194
F8.05 PWMselection
0:PWM mode1
1:PWM mode 2
0 × 195
F8.06
Torque setting
mode selection
0: Keyboard setting torque（100.0% is equal to the
value of F1.19）
1: Analog AVI setting torque（100.0% is equal to
the value of F1.19）
2: Analog ACI setting torque（100.0% is equal to
0 ○ 196
