ACD320 user manual Parameter Description
- 79-
factory value, and fine control relevant parameter.
Function Code Name Setting Range
Default
Value
F3.03
STOP function option
0: Keypad control valid
1: Keypad and terminal
control valid
2: Keypad and
communication
control valid
3: All controlmodes valid
0
This function code is to define the STOPstop function validity options.
Function Code Name Setting Range
Default
Value
F3.04 Reserved 0
Function Code Name Setting Range
Default
Value
F3.05
operation status display
parameter option
0-65535 1183
F3.06
Stop status display
parameter option
0-65535 207
F3.07
operation status display p
eferential option
0～15(0:invalid) 0
Operation status display:
Displayed Message Code
F3.07
code
BIT0: Running frequency
1 1
BIT1: Setting frequency
2 ******
BIT2: Output current
4 2
BIT3: Output voltage
8 3
BIT4: Running speed
16 4
BIT5: Output power
32 5
BIT6: Output torque
64 6
BIT7: DC bus voltage
128 7
