ACD320 user manual Parameter Description
- 80-
BIT8: PID setpoint
256 8
BIT9: PID feedback
512 9
BIT10: Input terminal status
1024 10
BIT11: Output terminal status
2048 11
BIT12: AVI value
4096 12
BIT13: ACI value
8192 13
BIT14: Current segment of
multi-speed control
16384 14
BIT15:Torque setting value 32768
15
Stop status display:
Displayed Message Code
BIT0:Setting frequency 1
BIT1:DC bus voltage 2
BIT2:Input terminal status 4
BIT3:Output terminal status 8
BIT4:PID setpoint 16
BIT5:PID feedback 32
BIT6:AVI value 64
BIT7:ACI value 128
BIT8:Current segment of multi-speed control 256
Option: setting parameter=the sum total of display code for example:
require to display at operation status:Output current,Running speed,Output power
4+16+32=52, then setting F3.05to 52 , its corresponding parameter can be viewed at operation
through pressing button "DATA".
This I/O terminal status is displayed in decimal system,S1 (MO1) corresponding to the
lowest digit.
For instance, input status displays 3 is indicting that terminal S1 and S2 are closed and
others are open.
For details, please see F3.17 and F3.18 description.
Input terminal state display with 10 hexadecimal, as following table:
Input terminal Effective Ineffective
MI1 1 0
MI2 2 0
MI3 4 0
MI4 8 0
MI5 16 0
