KEB COMBIVERT F5 Reference Manual

122
LI - Input Parameters
Digital Speed Selection
Utilizes four inputs to select up to ve different speeds.
Older KEB elevator software and worldwide variants are available. Because of
this, several different truth tables for the Digital Speed Selection are available:
Version: LI03 Setting: NUM
US Lift D(Level - Correct. - High - Inspect.) 0
KEB (DE) D(Level - High - Inspect. - Interm.) [Level at Start] 4
SFKEB D(Inspect. - Level - High - Interm.) 8
- D(Level - Int.2 - High - Inspect.) 12
The following are the corresponding logic tables. Although inputs I1...I4 are
shown, the inputs actually used for speed selection are congurable and
can be dened in LI04-11. Refer to Section 3.1.1 or 3.2.2 for input terminal
assignments.
LI03 = D(Level - Correct. - High - Inspect), NUM = 0
US04
Digital Speed
Selection
Param. Control Inputs
I1 I2 I3 I4
S
ZERO
- 0 0 0 0
S
LEVELING
LS01 1 0 x x
S
HIGH SPEED
LS02 0 0 1 x
S
INSPECTION
LS03 0 0 0 1
S
CORRECTION
LS04 0 1 x x
S
INTERMEDIATE 1
LS05 1 1 0 x
Symbol: 1 = Input is active
0 = Input is not active
x = Setting has no effect or doesn’t care
