LI - Input Parameters
Allows a custom input logic table to be dened for binary speed control mode, US04
Control Type = Binary Speed Selection (1). This parameter must be adjusted as
a hexadecimal number using the NUM function on the keypad when editing.
To select this function, set LI03 Speed Input Decoding = Decode with LI16.Speeds
are assigned the following values:
2 = Leveling
4 = Correction
6 = Inspection
8 = High
A = Intermediate 1
C = Intermediate 2
E = Intermediate 3
The parameter is 7 digits, populated one digit at a time with the above values to
create the decoding. The rst, right-most digit corresponds to binary 001 and the
seventh, left-most digit corresponds to binary 111 where I8>...>I1. Zero speed is xed
with binary 000.
I4 I3 I2 Digit
0 0 0 -
0 0 1 1 (Right-most)
0 1 0 2
0 1 1 3
1 0 0 4
1 0 1 5
1 1 0 6
1 1 1 7 (Left-most)
For example, the binary input logic table corresponding to the default setting of LI03
Speed Input Decoding = B(Level - Correction - Inspection), NUM = 0, would be LI16
= ECA8642 (note the order of the inputs).
Binary Speed
Selection
Parameter
Control Inputs
LI16 Value
I2 I3 I4
S
ZERO
- x x x -
S
LEVELING
LS01 1 0 0 2
S
CORRECTION
LS02 0 1 0 4
S
INSPECTION
LS03 1 1 0 6
S
HIGH
LS04 0 0 1 8
S
INTERMEDIATE 1
LS05 1 0 1 A
S
INTERMEDIATE 2
LS06 0 1 1 C
S
INTERMEDIATE 3
LS07 1 1 1 E
LI16
Custom Input
Decoding
To Next Page
