KEB COMBIVERT F5 Reference Manual

162
LE - Encoder Parameters
X3B Encoder Output / Input 2
Parameters LE31…LE36 correspond to encoder interface 2, X3B.
• Parameters LE32...34 and 36...39 correspond to encoder interface
2, X3B as an input.
• Parameter LE35 corresponds to encoder interface 2, X3B as an
output.
This parameter displays the type of encoder feedback for X3B.
This refers to X3B as an encoder input. Enter the encoder pulses per revolution
(ppr) listed on the encoder.
Refer to parameter LE03 for description.
Refer to parameter LE04 for description.
LE31
Encoder 2 Interface
LE32
Encoder 2 Pulse
Number
LE33
Swap Encoder 2
Channels
LE34
Sample Rate for
Encoder 2

KEB COMBIVERT F5 Specifications

General

Category	DC Drives
Enclosure Rating	IP20
Control Mode	Vector Control, V/f Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Fieldbus Communication	PROFIBUS, CANopen
Communication Interfaces	RS-485
Input Voltage	380-480V AC
Cooling Method	Forced air cooling (fan)
