LS - Speed Prole Parameters
The run prole is dened by jerks, acceleration, and deceleration.
Different run proles are available based on selected speed and/or input
function (e.g. Emergency Prole). The speed proles and corresponding
parameters are broken down into the following groups:
• High Speed/Correction Prole LS20-27
(Earthquake, Emergency Generator,
• and Battery Operation Speed)
• One Floor Prole (Intermediate Speeds 1, 2) LS30-38
• Emergency Prole (Intermediate Speed 3) LS40-47
• ESD/ETS Prole LS48-49
• Inspection Speed Prole LS50-55
Each prole will have the following settings*:
Acceleration
Starting Jerk
Acceleration Jerk
Deceleration
Deceleration Jerk
Stopping Jerk
*ESD and ETS Prole will only have deceleration and deceleration jerk settings.
Acceleration
Accel Jerk
Decel Jerk
Deceleration
Stop Jerk
Start Jerk
Final Stop
All speeds will use the LS43-45 deceleration and jerk settings for the
Final Stop portion of the prole.
