KEB COMBIVERT F5 Reference Manual

252
DG - Diagnostics Parameters (Combivis only)
The following table describes the various inverter statuses and the value
corresponding to each.
Value: Description:
0 No Operation
1 EOP - Error Over Voltage
2 EUP - Error Under Voltage
3 EUPh - Error Input Phase Failure
4 EOC - Error Over Current
5 EIPh - Error Output Phase Failure
6 EOHI - Error Overheat Internal
7 EnOHI - No Error Overheat Internal
8 EOH - Error Overheat Power Module
9 EdOH - Error Motor Overheat
11 EndOH - No Error Motor Overheat
12 EPU - Error Power Unit
13 no_PU - Power Unit Not Ready
15 ELSF - Error Charge Relay Fault
16 EOL - Error Overload
17 EnOL - No Error Overload
18 EbuS - HSP5 Serial Comm.
19 EOL2 - Error Overload Low Speed
20 EnOL2 - No Error Overload Low Speed
23 ESbuS - Error Bus Synchronization
24 EACC - Error Maximum Acceleration
25 ESCL - Error Speed Control Limit
30 EOH2 - Error Motor Protection
31 EEF - Error External Fault
32 EEnC1 - Error Encoder 1
34 EEnC2 - Error Encoder 2
35 EEnCC - Error Encoder Interface
36 EnOH - No Error Overheat Power Module
39 ESEt - Error Set
44 ESLF - Error Software Limit Forward
45 ESLr - Error Software Limit Reverse
46 EPrF - Error Protection Rotation Forward
47 EPrr - Error Protection Rotation Reverse
49 EPuci - Error Power Unit Code Invalid
50 EPuch - Power Unit Changed
51 Edri - Error Driver Relay
52 EHyb - Error Encoder Card
DG02
Inverter Status
