KEB COMBIVERT F5 Reference Manual

310
Parameter Reference
I = Induction Geared, IX = Induction Gearless, P = PM Geared, PX = PM Gearless
Para. Name
Hex v1.72 Motor/Gear Type
Setting
Options
NUM
Range Units Default
Pass
Level
I IX P PX Min. Max. Imp. Met.
LI04 Input 1 Function (I1)
0384 -
No Function*
UPS Operation*
Reduced Torque*
Emergency Prole*
Emergency Generator Speed*
Fault Reset
External Fault
Brake Release Conrm.
Main Contactor Check
Earthquake Speed
Emergency Slowdown (ESD)
Position Selection
Position Deviation Reset
Teach Value
Up Direction
Down Direction
Speed Selection
ETS (Emergency Terminal
Slowdown)
NTS1 (Normal Terminal Slowdown
NTS2
NTS3
Inspection Speed
Regen Fault
Braking Transistor On
125% NTS
*Can be selected together
0
1
2
4
8
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
- - - - No Function OEM
LI05 Input 2 Function (I2)
0385 - Same as LI04 “ - - - - No Function OEM
LI06 Input 3 Function (I3)
0386 - Same as LI04 “ - - - - No Function OEM
LI07 Input 4 Function (I4)
0387 - Same as LI04 “ - - - - No Function OEM
LI08 Input 5 Function (I5)
0388 - Same as LI04 “ - - - - No Function OEM
LI09 Input 6 Function (I6)
0389 - Same as LI04 “ - - - - No Function OEM
LI11 Input 8 Function (I8)
038B - Same as LI04 “ - - - - No Function OEM
LI15 Direction Selection Inputs
038F -
Direction Selection
Up and Down Inputs
Down Input Only
Up & Down AND Serial Control
Word
0
1
2
- - - -
(0); Up and
Down Inputs
+ Function
by Direction
Inputs
OEM
Brake Function
Function by Direction Inputs
Function by Speed Selection
0
4
LI16 Custom Input Decoding
0390 - - - 00000000h 00000000h OEM
LI20 Brake Switch Function
0394 -
General Reset
3 Auto Resets
Forced Reset
0
1
2
- - - -
General
Reset
OEM
LI50 UPS Mode
03B2 -
Default
Easy Direction
0
1
- - - - Default OEM
LI60 Correction is Inspection
03BC
Off
On
0
1
- - - - Off OEM
LM01 Motor Power
0681 LF10
-
-
-
0.5 299.5 HP - 10
Basic
0.3 225 - kW 7. 5
RO RO
0.5 299.5 HP - Calculated
0.3 225 - kW Calculated
LM02 Motor Speed
0682 LF11 - -
20 4000 rpm - 116 4
Basic
400 4000 - rpm 1450
20.0 500.0
rpm
100.0
400 4000 1000
20.0 500.0 100.0
LM03 Motor Current
0683 LF12 - - 1. 0 1000.0 Amps 1. 0 Basic
LM04 Motor Frequency
0684 LF13 - -
4.0 200.0 Hz - 60.0
Basic4.0 200.0 - Hz 50.0
4.0 200.0 Hz 50.0
LM05 Motor Voltage
0685 LF14 - -
10 32000 V 400
Basic
10 500 V 100
LM06 Motor Power Factor
0686 LF15 - -
0.5 1.00 - 0.90
Basic
NA NA NA NA NA
