KEB COMBIVERT F5 Reference Manual

318
Parameter Reference
I = Induction Geared, IX = Induction Gearless, P = PM Geared, PX = PM Gearless
Para. Name
Hex v1.72 Motor/Gear Type
Setting
Options
NUM
Range Units Default
Pass
Level
I IX P PX Min. Max. Imp. Met.
LX01 Auto Reset
0D81 LF5 - - 0 10 - - 5 Basic
LX02 Switching Frequency
0D82 LF38
8 kHz
12 kHz
16 kHz
4 kHz
0
1
2
3
- - kHz 8 Basic
LX06 Function Test
0D86 US37
Off
Fans On
0
1
- - - - Off Basic
LX07
Carrier Frequency
Handling
0D87 -
Off
Switching Freq. Management
Heatsink Temp. Dependence
Switching Freq. Management &
Heatsink Temp. Dependence
0
1
2
3
- - - - 3 OEM
LX08 Phase Current Check
0D88 US25
Mag. Current Check
Phase Current Check
0
1
- - - - 1 Adjuster
LX09 Watchdog Time
0D89 US29 - - Off (0) 10.00 sec 1.00 Adjuster
LX10 EdOH Function
0D8A US33
Off
On
0
1
- - - - Off Adjuster
LX11 Reference Splitting
0D8B US35 - - 0 127 msec 0 OEM
LX12 Baud Rate
0D8C US36
1200 bps
2400 bps
4800 bps
9600 bps
19200 bps
38400 bps
55500 bps
115200 bps
0
1
2
3
4
5
6
7
- - bps 38400 OEM
LX13 Speed Following Error
0D8D LF57
Warning - Digital Output
On with Error % Contract Speed
On with Error % Command Speed
0
1
2
- - - -
Warning-
Digital
Output
Adjuster
LX14 Speed Difference
0D8E LF58 - - 1 50 % 10 Adjuster
LX15 Speed for Pre-Opening
0D8F - -
- 1 100 ft/min - 59
Adjuster
- 0.005 0.508 - m/s 0.300
LX16 Decel Conrmation Speed
0D90 - -
- 0 1600 ft/min - 0
Adjuster
- 0.000 8.128 - m/s 0.000
LX17 ETS Speed
0D91 - -
- 0 1600 ft/min - 0
Adjuster
- 0.000 8.128 - m/s 0.000
LX18 Braking Resistance
0D92 - - - 0.0 200.0 Ohm 0.0 Adjuster
LX 21 Unintended Motion
0D95 -
Off
On
0
1
- - - Off OEM
LX22 Encoder Deviation Value
0D96 - - - 0 25,000 - 5,000 OEM
LX23 Encoder Deviation Enable
0D97 -
OFF
On with Error
0
1
- - - Off OEM
LX25
Unintended Motion
Distance
0D99 - - -
1. 9 19.6 in - 7.875
OEM
50 500 - mm 200
CH01 Default Parameters
0F81 -
Off
Factory Reset
0
1
- - - - Off Basic
CH02 Save Parameters
0F82 -
Off
Save to ash
Write to drive
0
1
2
3
- - - - Off Basic
CH03 Restore Parameters
0F83 -
Off
Restore from ash
Load Parameter List
Restore from drive
Load Motor Data
0
1
2
3
4
- - - - Off Basic
CH05 Motor Type
0F85 0 76 - - Basic
CH06 Rope Ratio
0F86
1:1
2:1
4:1
0
1
2
- - - - 1:1 Basic
CH07 Contract Speed
0F87
See parameter description
0 14 ft/min m/sec Basic
CH08 Car Capacity
0F88
See parameter description
0 11 lbs kg Basic
CH09 Program the selection
0F89
Off
Program
0
1
0 1 - - Off Basic
