KEB COMBIVERT F5 Reference Manual

323
Parameter Reference
I = Induction Geared, IX = Induction Gearless, P = PM Geared, PX = PM Gearless
Para. Name
Hex v1.72 Motor/Gear Type
Setting
Options
NUM
Range Units Default
Pass
Level
I IX P PX Min. Max. Imp. Met.
FB02 Field Bus Speed
1282
RO RO RO RO
- - -32767 32767 - - - OEM
FB03 Field Bus Pretorque
1283
RO RO RO RO
- - -100 100 % - OEM
FB04 Field Bus Target Position
1284
RO RO RO RO
- - -2147483647 2147483647 - - - OEM
FB05 Fb Control Word Mask
1285 - - 0h FFFFh - - FFFFh OEM
FB06 Speed Scale Multiplier
1286 - - 0 65535 - - 1 OEM
FB07 Speed Scale Right Shift
1287 - - 0 15 - - 0 OEM
FB08 Position Scale Multiplier
1288 - - 0 65535 - - 1 OEM
FB09 Position Scale Right Shift
1289 - - 0 15 - - 0 OEM
FB10 DIN66019 Fb Node ID
128A - - 1 128 - - 1 OEM
FB11 DIN66019 Fb Baud Rate
128B
9600 bps
19200 bps
38400 bps
55500 bps
115200 bps
0
1
2
3
4
- - - - 38400 OEM
FB12 DIN66019 Fb Watchdog
128C - - 20 1000 ms 50 OEM
FB13 PDO1 Map Assignment
128D - - 11810101h 11C0FF04h - - OEM
FB14 PDO2 Map Assignment
128E - - 118 10101h 11C0FF04h - - OEM
FB15 PDO3 Map Assignment
128F - - 118 10101h 11C0FF04h - - OEM
FB16 PDO4 Map Assignment
1290 - - 11810101 h 11C0FF04h - - OEM
FB17 PDI1 Map Assignment
1291 - - 12810102h 1284FF04h - - OEM
FB18 PDI2 Map Assignment
1292 - - 12810102h 1284FF04h - - OEM
FB19 PDI3 Map Assignment
1293 - - 12810102h 1284FF04h - - OEM
FB20 PDI4 Map Assignment
1294 - - 12810102h 1284FF04h - - OEM
FB21 Fb Special Function 1
1295
No Function*
UPS Operation*
Reduced Torque*
Emergency Prole*
Emergency Generator Speed*
Fault Reset
External Fault
Brake Release Conrm.
Main Contactor Check
Earthquake Speed
Emergency Slowdown (ESD)
Position Selection
Position Deviation Reset
Teach Value
Up Direction
Down Direction
Speed Selection
ETS (Emergency Terminal
Slowdown)
NTS1 (Normal Terminal Slowdown
NTS2
NTS3
Inspection Speed
*Can be selected together
0
1
2
4
8
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
- - - - No Function OEM
FB22 Fb Special Function 2
1296 Same as FB21 ““ - - - - No Function OEM
FB23 Fb Special Function 3
1297 Same as FB21 ““ - - - - No Function OEM
FB24 Fb Special Function 4
1298 Same as FB21 ““ - - - - No Function OEM
FB25 Fb Special Function 5
1299 Same as FB21 ““ - - - - No Function OEM
FB26 Fb Special Function 6
129A Same as FB21 ““ - - - - No Function OEM
FB27 Fb Special Function 7
129B Same as FB21 ““ - - - - No Function OEM
FB30 PDO1 Data
129E
RO RO RO RO
- - 80000000h 7FFFFFFFh - - - OEM
FB31 PDO2 Data
129F
RO RO RO RO
- - 80000000h 7FFFFFFFh - - - OEM
FB32 PDO3 Data
12A0
RO RO RO RO
- - 80000000h 7FFFFFFFh - - - OEM
FB33 PDO4 Data
12A1
RO RO RO RO
- - 80000000h 7FFFFFFFh - - - OEM
FB34 PDI1 Data
12A2
RO RO RO RO
- - 80000000h 7FFFFFFFh - - - OEM
FB35 PDI2 Data
12A3
RO RO RO RO
- - 80000000h 7FFFFFFFh - - - OEM
FB36 PDI3 Data
12A4
RO RO RO RO
- - 80000000h 7FFFFFFFh - - - OEM
FB37 PDI4 Data
12A5
RO RO RO RO
- - 80000000h 7FFFFFFFh - - - OEM
FB50 Temp DIN Com Err. Cnt.
12B2 - - 0 65535 - - 0 OEM
