Model 4200A-SCS Pulse Card (PGU and PMU) User's Manual Section 4: Pulse card concepts

4200A-PMU-900-01 Rev. A December 2020 4-29

Example: pulse_meas_sm

This function sets channel 1 of the PMU for the spot mean discrete measure type to acquire the

voltage amplitude measurement, the current base level measurement, and the time stamps. It also

enables LLEC for amplitude:

pulse_meas_sm(PMU1, 1, 0, 1, 0, 1, 0, 1, 1);

Where:

• Instr_id = PMU1

• chan = 1 (channel 1)

• AcquireType = 0 (discrete)

• AcquireMeasVAmpl = 1 (enable)

• AcquireMeasVBase = 0 (disable)

• AcquireMeasIAmpl = 1 (enable)

• AcquireMeasIBase = 0 (disable)

• AcquireTimeStamp = 1 (enable)

• LLEComp = 1 (enable)

Example: pulse_meas_wfm

This function sets channel 1 of the PMU for the waveform discrete measure type to acquire the

voltage/current readings for the waveform and the time stamps. It also enables LLEC.

pulse_meas_wfm(PMU1, 1, 0, 1, 1, 1, 1);

Where:

• Instr_id = PMU1

• chan = 1 (channel 1)

• AcquireType = 0 (discrete)

• AcquireMeasV = 1 (enable)

• AcquireMeasI = 1 (enable)

• AcquireTimeStamp = 1 (enable)

• LLEComp = 1 (enable)
