Section 4
:
Pulse card concepts
Model 4200A-SCS Pulse Card (PGU and PMU) User's Manual
4-
30
4200A
-PMU-
900
-01 Rev. A D
ecember 2020
Example: pulse_mea
s_timing
This function sets the fo
llowing pulse measure timing
settings for five spot mea
n measurements for
channel 1 of PMU1:
pulse_meas_timing(PMU1, 1, 0.6, 0.8, 5);
Wher
e:
•
Instr_id
= PMU1
•
chan
= 1 (channel 1)
•
StartPercent
= 0.6 (60%)
•
StopPercent
= 0.8 (80%)
•
NumPulses
= 5 (output one pu
lse)
118
120
