To configure other installed pulse cards for Custom File Arb, repeat steps 1 through 6.
7. Select the green triangle to turn on enabled channels for all installed pulse cards in the
4200A-SCS. With the output on, the square box turns red. To turn off the outputs of all pulse
cards, select the red box.
Waveform types
KPulse provides the following fundamental waveform types to use as the building blocks for custom
file arb:
• Sine waveform (on page 5-14)
• Square waveform (on page 5-14)
• Triangle waveform (on page 5-15)
• Custom waveform (on page 5-15)
• Calculation waveform (on page 5-17)
• Noise waveform (on page 5-17)
• Gaussian waveform (on page 5-18)
• Ramp waveform (on page 5-18)
• Sequences waveform (on page 5-20)
As explained in Custom Arb file operation: Select and configure waveforms (on page 5-9), a
waveform is created using the Waveform Generator. After selecting and configuring one of the above
waveform types, the waveform is placed into the Scratch Pad.
The period for the waveforms is determined by the Time Per Point setting in the Arb Generator tab
(refer to Custom Arb file operation: Copy waveforms into Sequencer (on page 5-10)).
