Model 4200A-SCS Pulse Card (PGU and PMU) User's Manual Section 6: Use the RPM to switch the SMU, CVU, and PMU
4200A-PMU-900-01 Rev. A December 2020 6-11
Figure 134: Test Settings pane and the Test Settings Advanced and Formulator dialog boxes
for the cv-diode sweep test
5. On the Terminal Settings pane and the Terminal Settings Advanced dialog box of the Anode
terminal, adjust the parameters.
If you are including cable compensation values, run the Tools menu option CVU Connection
Compensation. Refer to “Perform offset compensation” in the Model 4200A-SCS
Capacitance-Voltage Unit (CVU) User's Manual for more detail.
