Voicetron
Figure 319
Figure 320
Figure 321
Figure 322
EFFECTS
By selecting the F9 button the list of EFFECTS similar
to Figure 319 will appear from which you can edit the
parameters of the REVERB and ECHO effects. Select
the parameter by using the CURSOR § ¶
buttons
and edit the value of the 3 parameters by using the
DATA/VALUE wheel. The three parameters are:
EFFECTS SEND (values 0–63)
REVERB PRESET (see the list at left)
ECHO PRESET (see the list at right)
REVERB PRESET
Short Room
Room
Small Hall
Large Hall
Short Plate
Vocal Plate
Church
Cathedral
Gated Reverb
Gated Plate
User1
User2
User3
ECHO PRESET
Mono
Stereo
Mono 3/4
Stereo 3/4
Mono 4/4
Stereo 4/4
Mono Triplet
Stereo Triplet
Mono Tap
Stereo Tap
Mono 3/4 Tap
Stereo 3/4 Tap
Mono 4/4 Tap
Stereo 4/4 Tap
Mono Triplet Tap
Stereo Triplet Tap
User1
User2
User3
VOCAL TO ARR.
By selecting the F10 button the VOCAL TO ARR.
screen like Figure 320 will appear where you can edit
the parameters of this function. The function allows
to set automatically a VOCALIZER effect associated
to the part played by the Arranger. For example, you
can set a DUET effect for the START, a TRIO effect
for the variation A of the Arranger, a VOCODER effect
for the variation B of the Arranger and so on. You can
make the choice of the part by using the CURSOR §
¶
bu
t
tons
while the effect to assign can be selected
by using the DATA/VALUE wheel or by using the F1-
F5 buttons (DUET, TRIO, QUARTET, QUINTET and
FIXED INTERV.) or the DATA/VALUE wheel.
Saving a VOCALIZER effect
Once finished, press the SAVE button on the front
1.
panel.
A dialogue will appear to give a name (
2.
Figure
321). Digit the name by using the keyboard and
press the USER 5 button (SAVE)
Once saved, you can recall the custom effect
3.
from the second page of the VOCALIZER window
(Figure 322).
