Keysight Technologies 34410A - Additional 34411 A;L4411 A Specifications

138 34410A/11A/L4411A User’s Guide
5 Specifications
Additional 34411A/L4411A Specifications
Resolution See table on page 130
Overall Bandwidth, DCV and DCI 15 kHz typical @ 20 µs aperture (–3 dB)
Triggering Pre or Post, Internal or External, Positive or Negative
Timebase Resolution 19.9524 µs, 0.01% accuracy
Trigger Jitter 2 µs(p-p), 20 µs(p-p) when pre-triggered
External Trigger Latency < 3 µs
Internal Trigger Level Accuracy 1% of range
Spurious-Free Dynamic Range and SNDR
[1] 10 V range specifications are valid for signals 2 V(p-p) < x(t) < 16 V(p-p)
[2] 100 µA range specifications are valid for signals 28.8 µA(p-p) < x(t) < 200 µA(p-p)
Function Range Spurious-Free
Dynamic Range
Signal to Noise
Distortion Ratio (SNDR)
DCV 100.0000 mV
1.000000 V
10.00000 V
[1]
100.0000 V
1000.000 V
–55 dB
–75 dB
–70 dB
–75 dB
–60 dB
40 dB
60 dB
65 dB
60 dB
55 dB
DCI 100.0000 µA
[2]
1.000000 mA
10.00000 mA
100.0000 mA
1.000000 A
3.00000 A
–50 dB
–65 dB
–45 dB
–65 dB
–65 dB
–70 dB
38 dB
50 dB
38 dB
50 dB
55 dB
55 dB
