40 34410A/11A/L4411A User’s Guide
2 Features and Functions
•OComp For resistance measurements in the 100 Ω, 1 kΩ and 10 kΩ ranges, offset
compensation is enabled.
• ManRng For the selected measurement function, a manual range is selected
(autoranging is off).
•Trig Triggering is enabled. The meter is in the “wait–for–trigger” state.
• Hold The reading hold function is enabled.
• Remote The multimeter is operating in the remote interface mode.
•Error A hardware error or remote interface error has been detected, and a message
is in the error queue.
•Null The null feature is enabled for the present measurement function.
•Shift The key has been pressed (toggles on and off).
• Math Either the dB or dBm math function is enabled.
• Stats The statistics math function is enabled.
• Limits The limit test math function is enabled.
•Rear The Front/Rear switch is set to Rear and the rear set of input terminals is
connected internally to make measurements.
•4WA four–wire resistance or temperature function is selected.
• The continuity function is selected.
• The diode test function is selected.
Second Display Options
Many measurement functions allow a secondary measurement to be displayed
simultaneously on the second display line:
• Front Panel Operation: Press
2ND DISPLAY > PK-TO-PK (Where primary function is voltage or current.)
Primary Function Second Display Function
DC V, DC I, AC V, AC I Peak–to–Peak value
Freq AC Voltage*
Temp Raw Resistance**
*ac voltage of the input waveform
**actual raw resistance measured across temperature probe and leads
