34410A/11A/L4411A User’s Guide 49
Features and Functions 2
Multimeter State Storage
The present multimeter state, including all settings for measurement configuration, math
operations, triggering operations, system operations and I/O configuration, can be saved
in one of five non–volatile stored states and later recalled. State 0 (POWER_DOWN)
retains the multimeter configuration at power down. States 1 – 4
(STATE_1, STATE_2, STATE_3, STATE_4) are available for storing other
configurations.
• Front Panel Operation:
Press to open the utility menu.
• To store the present multimeter state (for example, to STATE_1):
UTILITY MENU > STORE/RECALL > STORE > STORE STATE > 1: STATE_1 >
CHANGE NAME
Use the navigation keypad to enter a new name (up to 12 characters), or just press
to store with the default name.
• To recall any of five stored states (for example: STATE_1):
UTILITY MENU > STORE/RECALL > RECALL > RECALL STATE > 1: STATE_1
• To delete a state you have stored (for example: STATE_1):
UTILITY MENU > STORE/RECALL > DELETE > DELETE STATE > 1: STATE_1
• To rename a state you have stored (for example: STATE_1):
UTILITY MENU > STORE/RECALL > RENAME > RENAME STATE > 1: STATE_1 >
CHANGE NAME
Use the navigation keypad to enter a new name (up to 12 characters), or just press
to store with the current name.
• To select any previously stored state (0 – 4) as the power–on default state (for
example: STATE_1):
UTILITY MENU > STORE/RECALL > PWR-ON > PWR-ON AUTO > ON > PWR-ON
STATE > 1: STATE_1
• Remote Interface Operation: Refer to the MEMory command subsystem in the
Keysight 34410A/11A/L4411A Programmer’s Reference Help for a complete
description and syntax of the commands that store, recall, and name multimeter states
from the remote interface.
