34410A/11A/L4411A User’s Guide 41
Features and Functions 2
Once the second display is enabled, you can scroll through all second display items,
including STATS or LIMITS if these functions are enabled.
• Remote Interface Operation: The following command selects the measurement or
math function to be displayed on the second display line. The <feed> parameter is
a
quoted ASCII string designating the function to be displayed, such as
VOLTage:PTPeak.
DISPlay:WINDow2:TEXT:FEED <feed>
The following query returns the currently selected
<feed>
parameter, as a quoted
ASCII string:
DISPlay:WINDow2:TEXT:FEED?
Refer to the Keysight 34410A/11A/L4411A Programmer’s Reference Help for
a
complete description and syntax for these commands.
Turning the Display Off
This feature is available from the remote interface only.
For security reasons, you may want to disable the front panel display. When disabled,
the entire front panel display (except for the Error and Remote annunciators) goes dark.
• Remote Interface Operation: The following command turns off the display:
DISPlay OFF
The following command queries the display setting:
DISPlay?
The query returns a “0” (OFF) or “1” (ON).
Refer to the Keysight 34410A/11A/L4411A Programmer’s Reference Help for
a complete description and syntax for these commands.
Front–Panel Display Shortcuts
Direct front–panel shortcuts are provided for three commonly used display functions:
ranging, digit masking, and integration time. These shortcuts are available only when
you are not in a menu.
Ranging. The meter range can be set directly from the navigation keypad.
• To manually change the range, press or . The ManRng annunciator lights, and
the selected range (for example, 100mV RANGE) is briefly displayed on the second
line.
• To toggle between the selected manual range and autoranging, press
.
The ManRng annunciator toggles on or off, as appropriate. Note: This is a
dual–function key, not a shifted key. Pressing
when in a menu will exit the
menu.
