22 34410A/11A/L4411A User’s Guide
1 Quick Start
• Configurable parameters: PROBE TYPE, THERMISTOR or RTD value, AUTO
ZERO, OFFSET COMP (RTD probes only), INTEGRATION, UNITS, NULL, and
NULL VALUE
To Make a 4-Wire Temperature Measurement
Press to select the temperature function. Then press and select
RTD-4W or THERMISTOR-4W from the menu.
• Probe types: 2.2 kΩ, 5 kΩ, 10 kΩ thermistors; 0.00385/°C RTD
• Configurable parameters: PROBE TYPE, THERMISTOR or RTD value, OFFSET
COMP (RTD probes only), INTEGRATION, UNITS, NULL, and NULL VALUE
All 4-wire temperature measurements are made with auto-zero on.
To Test Continuity
Press to select the continuity function.
• Test current source: 1 mA
Connect test leads as shown:
Thermistor or RTD
Connect test leads as shown:
Thermistor or RTD
