16 34410A/11A/L4411A User’s Guide
1 Quick Start
Integration Time (Bandwidth, Gate Time). Four measurement functions allow
you to select the multimeter’s integration time: dc voltage, dc current, resistance, and
temperature. The ac voltage and current measurements allow you to select the ac signal
filter (bandwidth). The frequency/period function allows you to select gate time. The
navigation keypad provides a shortcut for quickly changing these settings.
• If the multimeter is configured to take the measurement using an integration time in
NPLCs, pressing or during front panel measurement operations will increase
or decrease the integration time setting.
• If either the ac voltage or ac current measurement function is selected, pressing
or during front panel measurement operations will increase or decrease the
bandwidth setting.
• If the frequency/period measurement function is selected, pressing or during
front panel measurement operations will increase or decrease the gate time setting.
