88 34410A/11A/L4411A User’s Guide
2 Features and Functions
Display State (34410A/11A) On
Reading Memory Cleared
Error Queue Cleared at Power
–On.
Not cleared by a front panel or remote
interface Reset command
● Stored States ● No change
● Calibration State ● Secured
Input/Output Configuration Factory Setting
Enable Interfaces:
1
● LAN ● Enabled
● GPIB ● Enabled
● USB ● Enabled
Lan Settings:
2
● DHCP ● On
● Auto IP ● On
● IP Address ● 169.254.4.10
● Subnet Mask ● 255.255.0.0
● Default Gateway ● 0.0.0.0
● DNS Server ● 0.0.0.0
● Host Name ● A-34410A-nnnnn (for 34410A)
3
● A-34411A-nnnnn (for 34411A)
● A-L4411A-nnnnn (for L4411A)
● LAN Services
1
● Enable All
GPIB Settings:
● GPIB Address ● 22
1 Interface enable or LAN service changes take effect only after you cycle power.
2 LAN setting changes require a LAN restart. From SCPI you must cycle power.
3 Where nnnnn represents the last 5 digits of the instrument serial number.
System–Related Operations Factory Setting
NOTE
The power-on/reset state may be different than that in the above tables if you have
enabled the power-on state recall mode (PWR-ON AUTO set to On from the Utility
menu). Also, you can recall one of four stored instrument states other than the power-on
state. See “Multimeter State Storage” on page 49 for further information.
