120 6000 X-Series Oscilloscopes Service Guide
6 Replaceable Parts
Replaceable Parts List
The information given for each part consists of the following:
• Reference designation.
• Keysight Technologies part number.
• Total quantity (Qty) in the instrument or on assembly.
• Description of the part.
Table 23 Replaceable Parts
Ref Des Keysight Part
Number
Qty Description
A1 54608-66601 1 Acquisition board 6000 X-Series 2-Ch
A1 54608-69501 1 Acquisition board 6000 X-Series 2-Ch (exchange)
A1 54608-69501-DEF 1 Acquisition board 6000 X-Series 2-Ch (return)
A1 54609-66601 1 Acquisition board 6000 X-Series 4-Ch
A1 54609-69501 1 Acquisition board 6000 X-Series 4-Ch - (exchange)
A1 54609-69501-DEF 1 Acquisition board 6000 X-Series 4-Ch - (return)
A2 54608-66421 1 PCA - 2 Channel Keyboard 6000 X-Series
A2 54609-66421 1 PCA - 4 Channel Keyboard 6000 X-Series
A3 0950-5492 1 Power Supply AC-DC 250W 1-Output
A4 54609-66422 1 PCA - Line Input, Power Conversion Board
A5 2090-1069 1 Display LCD 12.1-in TFT SVGA with P-CAP touch Panel
Not shown 54684-42202 2 Hole plug front panel (2 Channel only)
Not shown 2950-0054 2 Nut, 1/2-28 THD (secures BNCs)
Not shown 2190-0068 2 Washer-LK Intl T 1/2 In. .505 IN-ID (for BNCs)
Not shown 0515-0374 36 Screw-Machine with Crest-Cup-Con-Washer Pan-HD Torx-T10 M3X0.5
10mm-LG SST-300 passivated finish
