22 6000 X-Series Oscilloscopes Service Guide
2 Testing Performance
Figure 1 Constructing the 8-by-2 Connector
Jumper (2)
Signal Lead
(from scope’s MSO cable)
8 x 2 Berg Strip
BNC Panel Mount Connector
Ground Lead
(from scope’s MSO cable)
