92 6000 X-Series Oscilloscopes Service Guide
5 Replacing Assemblies
To remove the probe power shield
1 To remove the probe power shield, locate and remove using a TORX T10 driver
the one screw securing the shield to the rear deck.
2 Once the screw has been removed, carefully remove the probe power shield by
lifting the cover up and off retaining tabs on rear deck.
Figure 25 Removing the probe power shield
WARNING
Thin sheet metal parts may have sharp edges. Handle with care to avoid injury.
